DY-GTL400C Handheld Dry Block Temperature Calibrator(Indoor Temperature +5℃-400℃)

Handheld Dry Block Temperature Calibrator, the test temperature range: indoor temperature +5℃-400℃.

Inquire Now

Product Introduction

Handheld Dry Block Temperature Calibrator, the test temperature range: indoor temperature +5℃-400℃. Hand-held, small size, easy to carry, and rapid heating. Completely solve the shortcomings of too long heating and temperature control time, saving time and effort to use. The hand-held intelligent dry-body furnace uses a high-stability temperature controller, and the soaking block is made of alloy materials with good thermal conductivity. It is technically synchronized with domestic and foreign advanced technologies, and is widely used in machinery, shipbuilding, chemical, food, electric power, pharmaceuticals and other industries.

Product Feature

1. Handheld operation and More lighter.Higher accuracy, resolution 0.1/0.01℃.

2.Rapid heating, temperature control.The temperature rise and control time only takes 10 minutes.

3. One-key temperature setting, easy operation, automatic adjustment of heating power.

Technical Indicators

Temperature Range(Indoor Temperature≤22℃)	Indoor Temperature +5℃-400℃
Display Resolution	0.1℃
Control Mode	PID Control
Stability	±0.15℃ %
Accuracy	±0.3℃ %
Depth of Checking Hole	115mm
Diameter of Checking Hole	25mm
Temperature rise time	15min(temperature rise from room temperature to upper limit + stable time)
Cooling time	20min (the upper limit temperature drops to 100℃)
Diameter of Checking Hole	3mm、6mm、8mm、10mm(Customizable)
Number of Checking Hole	4(Customizable)
Size(Height* Width* Length)	90×160×250mm
Weight	1.8KG
Power Supply	220V AC 50HZ 400W
Standard Accessories	Power line* 1 Specification * 1 Product Manual*1
