DY-GJC2 Steel Tape Measuring Device

The DY-GJC2 steel tape measure calibration device is designed and developed by Taian Demei Electromechanical Equipment Co., Ltd. in accordance with the new JJG4-2015 "Steel Tape Measure Calibration Regulations". This calibration device can be used to calibrate steel tape measures.

This calibrator can be used to calibrate the indication error of conventional measuring tools such as steel tape measures, steel tape measures, depth oil dipsticks, steel circumference rulers, fiber tape measures, steel plate rulers (steel plate rulers can only be used for comparative testing, not for standardization); if equipped with a zero position calibration table, the zero position deviation of the depth oil dipstick can be compared and calibrated.

Inquire Now

Steel tape calibration device model

DY-GJC2 type (digital display type) analog

DY-GJC2 Steel Tape Measuring Device

Basic configuration: 1*5m standard ruler, 1*calibration table, 1*small pulley, 1*reading microscope, 2*tape clamps, 2*5kg weights, 1*digital display box, 1*power supply.

The device uses a grating displacement sensor with a standard steel tape measure as the instrument measurement data collection, and the measurement result data will be directly given through PLC data processing. Reduced manual labor intensity.

Optional parts:

Zero position calibrator (must be equipped for calibrating the dipstick)

Weight lifting device (auxiliary lifting weight, reducing manual labor intensity)

Substrate: 2 pcs

Ultrasonic calibration sheet

Ultrasonic thickness block: 17 pcs

Round standard block: 2 pcs

Product Feature of Steel Tape Calibration Device

1) This calibrator has a simple structure, easy installation, beautiful and practical appearance.

2) The main parts (weight and handle) are all electroplated, with a bright and elegant appearance.

3) It is equipped with a weight unloading device, which can easily control loading and unloading.

4) It is equipped with a reading microscope, which can conveniently and clearly display the error of the ruler being tested.

5) The reading microscope is equipped with a lighting device, which makes the image very clear.

6) The reading microscope and the lighting device are installed on the measuring vehicle, which can be easily operated. The measuring vehicle can be removed as a whole for easy storage and maintenance.

7) The standard ruler and the ruler being tested are lifted up by using the support shaft, which eliminates the friction between the ruler tape and the table, thereby improving the detection accuracy.

Technical Indicators of Steel Tape Calibration Device

The device can detect items: Level 1, Level 2 ordinary steel tape measure. Depth measuring steel tape measure (oil dipstick). Fiber tape measure. Measuring rope and other large-scale measuring tools.

1. Overall length of the calibration table: 5.3m (total length is about 5.9m, which can be extended to 50m in 5m sections according to user requirements)

2. Effective detection length: 5m (using segmented detection measurement range: (5-200)m)

3. Standard steel tape measure accuracy: (0.02+0.02L)mm

4. Calibration table guide straightness: ≤0.3mm/m

5. Overall static friction of the calibration table: ≤4N

6. Instrument minimum resolution: 0.01mm

7. The instrument comes with a lighting device

8. Reading microscope: 20X 0.01mm
