DY-HT1A Low Temperature Blackbody Furnace(-40℃-80℃)

The temperature range of the black body temperature calibrator is -40℃~80℃.Blackbody radiation source, mainly used for calibrating radiation thermometers, infrared thermometers and radiation temperature sensing detectors.

The product is small in size, light in weight and easy to carry. It is not only suitable for the use of radiation thermometers in the laboratory calibration of measuring institutions at all levels, but also for on-site calibration.

Inquire Now Next Product

Product Introductiondry of Block Calibration Bath

As a standard radiation source, standard black bodies are mainly used to calibrate radiation thermometers, infrared thermometers and radiation temperature sensor detectors. Our company currently has advanced black body technology, a full range of black body products with a wide temperature range. The products are small in size, light in weight and easy to carry. They are not only suitable for calibrating radiation thermometers in laboratories of metrology institutions at all levels, but can also be used for on-site calibration.

Product Feature of Blackbody Radiation Source

1. More portable and lighter.Higher accuracy.

2. Human-machine interface, touch operation.

3. One-key temperature setting, easy to operate.Rapid heating, temperature control.

4. Can copy the language interface of any place in the world according to customers' requirements for export convenience.

Technical Indicators of Blackbody Radiation Calibration

Model	DY-HT1A
Temperature Range	-40℃-80℃
Control Mode	Touch Screen
Temperature Resolution	0.1℃/0.01℃
Temperature Control	PID Automatic Control
Cavity Diameter	Φ40mm(Customizable)
Emissivity	≥0.995
Temperature Stability	Larger than 0.1℃ and 0.1% T (T is the radiation source temperature)
Temperature Uniformity	Larger than ±0.15℃ and 0.15% T (T is the radiation source temperature)
Power Supply	220V AC 50HZ
Power	500W
Dimension(L×W×H)	370mm×250mm×370mm
Weight	8.5Kg

Note: other special requirements can be customized according to the needs of users

Picture of Blackbody Source

DY-HT1A Low Temperature Blackbody Furnace(-40℃-80℃)
